Objects Session Notes
Bullet C/2007 N3 (Lulin) - Comet
Bullet M1 - Supernovae Remnant
Bullet Moon
Bullet NGC 2392 - Planetary Nebula ("Eskimo Nebula")
Bullet M97 - Planetary Nebula (Owl Nebula)
Bullet Saturn
Bullet M13 - Globular Cluster
Bullet M101 - Spiral Galaxy
Bullet M81 - Spiral Galaxy (Bode's Nebula)
Bullet M82 - Spiral Galaxy

Bullet Astrometric & Photometric Monitoring
- None
- FIRST LIGHT FOR 12" LX200 ACF + ST-10XME
- Evening session (4.9 hrs), largely operated under direct control via observatory laptop.
- Ambient Temperature  : not recorded (est. 5 deg C)
- CCD operation -25 degC (at 56% average cooling).
- main objective of the session was  to test new LX200R telescope and ST-10XME/CFW10 under night sky conditions.
- as part of the testing opportunity was taken to acquire images of a number of objects
- Notes from 2009-03-09

Images taken during first night's imaging with 12" LX200 ACF + ST-10XME

Note : Images below were taken at approximately full moon, before any balance and collimation adjustments and without periodic error correction or quantitative focusing.  Reduction was with a dithered master night flat.  Later tests showed that polar alignment was fairly good. but that scope balance was extremely compromised by the heavy CCD/Filter Wheel equipment.

Stars are somewhat bloated due to some mis-collimation and elongated due to PEC and poor scope balancing.

A more detailed review of the equipment performance (including some 'poorer' image examples) is included on the Session's Notes Page (2009-03-09)

Back to Top


C/2007 N3 (Lulin) - Comet

C/2007 N3 (Lulin) passing through starfield in Leo

CCD Image (Linear Scale)
30s sec exposure, 3x3 binning, C Filter
2009-03-09 21:08 h UT (#356006)
12" LX200R  (at f/5.8) + ST-10XME

CCD Image (Linear Scale)
30x30s sec exposure (average, aligned on comet, 3x3 binning, C Filter
2009-03-09 21:08 h UT (#356006-35)
12" LX200R  (at f/5.8) + ST-10XME


CCD Image (Linear Scale)
3 x 30s sec exposure (average combine, aligned on comet),
2x2 binning, C Filter
2009-03-09 21:09 h UT (#356006-08)
12" LX200R  (at f/5.8) + ST-10XME



C/2007 N3 (Lulin) - detail


False Colour CCD Image (Log Scale)
Inverse Specturn
30s sec exposure,  2x2 binning, C Filter
2009-03-09 21:08 h UT (#356006)
12" LX200R  (at f/5.8) + ST-10XME

Back to Top


M1 - Supernovae Remnant

M1 (Taurus)

CCD Image (50% size)
5 x 60s exposure (average combine), 3x3 binning, C Filter
Linear brightness scaling
2009-03-09 21:48 h UT  (#356039-50)
12" LX200R  (at f/5.8) + ST-10XME


M1 - detail

CCD Image (125% size)
5 x 60s exposure (average combine)
Image details as above

Back to Top


Moon

Moon

CCD Image (linear scale, sharpened)
0.12 sec exposure, 3x3 binning, U Filter
2009-03-09 22:08 h UT  (#356063)
12" LX200R  (at f/5.8) + ST-10XME



Moon - detail

CCD Image (linear scale, sharpened, cropped)
0.12 sec exposure, 3x3 binning, U Filter
2009-03-09 22:16 h UT  (#356095)
12" LX200R  (at f/5.8) + ST-10XME



CCD Image (linear scale, unsharp masked, cropped, 60% size scale)
0.3 sec exposure, 1x1 binning, U Filter
2009-03-09 22:16 h UT  (#356090)
12" LX200R  (at f/5.8) + ST-10XME



CCD Image (linear scale, unsharp masked, cropped)
6 x 0.12 sec exposure (average combine), 2x2 binning, U Filter
2009-03-09 22:07 h UT  (#356056-61)
12" LX200R  (at f/5.8) + ST-10XME

Back to Top


NGC 2392 - Planetary Nebula ("Eskimo Nebula")

NGC 2392 (Gemini)


CCD Image (square root scaling)
3 x 30 sec (average combine), 2x2 binning (half-frame), C Filter
2009-03-09 22:22 h UT  (#356101-03)
12" LX200R  (at f/5.8) + ST-10XME



NGC 2392 - detail


CCD Image (square root scaling, 200% size)
Image details as above

Back to Top


M97 - Planetary Nebula (Owl Nebula)

M97 (Ursa Major)

CCD Image (linear scale, cropped)
3 x 60 sec exposure (average frame), 3x3 binning, C Filter
2009-03-09 22:59 h UT  (#356129-31)
12" LX200R  (at f/5.8) + ST-10XME

M97 - later image (2009-04-22)

CCD Image (cropped)
5 x 90 sec exposure (average frame), 3x3 binning, C Filter
2009-04-22 01:05 h UT  (#364272-75)
12" LX200R  (at f/5.8) + ST-10XME

Back to Top


Saturn

Saturn

CCD Image (cropped)
0.2 sec exposure (single frame), 1x1 binning, C Filter
2009-03-10 00:08 h UT  (#356183)
12" LX200R  (at f/5.8) + ST-10XME

Back to Top


M13 - Globular Cluster

M13 (Hercules)
CCD Image (Square root scaling)
10s, 2x2 binning, R Filter
2009-03-10 00:20 h UT  (#356196)
12" LX200R  (at f/5.8) + ST-10XME

Back to Top


M101 - Spiral Galaxy

M101 (Ursa Major)
CCD Image (75% size)
3 x 3 min (average combine),  3x3 binning, C Filter
2009-03-10 00:54 h UT  (#356245-49)
12" LX200R  (at f/5.8) + ST-10XME

Back to Top


M81 - Spiral Galaxy (Bode's Nebula)

M81  (Ursa Major)
Image Image
CCD Image (linear scale, 50% size)
90 sec exposure (single frame), 3x3 binning, C Filter
2009-03-10 01:29 h UT  (#356259)
12" LX200R  (at f/5.8) + ST-10XME
CCD Image (square root scale, 50% size)
Image details as left

Image Image
CCD Image  (log root scale, 50% size)
False Colour (Cold)
Image details as above
CCD Image  (log root scale, 50% size)
False Colour (Inverse Spectrum)
Image details as above left

Back to Top


M82 - Spiral Galaxy

M82 (Ursa Major)
CCD Image (Square root scaling, 55% size)
9 x 20s (median combine), 3x3 binning, C Filter
2009-03-10 01:40 h UT  (#356266-74)
12" LX200R  (at f/5.8) + ST-10XME
[full size image]
CCD Image (Square root scaling, cropped)
Image details as above

Back to Top


Astrometric and Photometric Monitoring
